Spectra-Siri S12® COVERED

Spectra-Siri S12® COVERED are High Modulus / High-Performance ropes with long-term fatigue life properties and outstanding quality performance ideal for the critical operations of the shipping industry. They consist of a 12-strand load-bearing core (Spectra^® fibers) and a protective braided cover. This rope construction is firm, round, and torque-free.

Applications

Spectra-Siri S12® COVERED ropes combine the excellent properties of Honeywell’s Spectra^® fibers and an insuperable manufacturing process. The use of the special NikaThane coating application on the Spectra^® fibers and the superior in-house Linear Structural Preformation (LSP) process provides a high-quality robust rope construction with higher strength efficiency and excellent abrasion resistance. Spectra-Siri S12® COVERED ropes exhibit excellent resistance to UV sunlight and weathering degradation and thus an extended service life (more than 7 years).

Spectra-Siri S12® COVERED ropes are an excellent wire-rope alternative and offer several benefits:

Most cost-effective ropes to purchase due to lower labor requirements in operations and decreased mooring & towing operating times
High strength-to-size ratio of the HC Spectra® fibers, allowing for lighter weight ropes that are easier to handle.
No corrosion, superior chemical resistance, increased abrasion resistance and excellent flex fatigue
2-3 times longer service life (compared to wire ropes)
Negligible maintenance costs

Spectra-Siri S12® COVERED ropes are produced according to the latest edition of ISO 10325 and they comply with OCIMF’s latest regulations & recommendations for the safe mooring of commercial vessels.

Specifications

Specific Gravity: 1.07 (PES jacket) / 1.00 (Mixed jacket) / 0.97 (UHMWPE jacket)
Elongation at breaking: 3.5% (when new)
Melting point: 145°C (UHMWPE) - 265°C (PES)
Resistance to UV radiation: Excellent
Chemical Resistance: Very Good

User's Manual

Technical Data

Nom. Size (Circ)	Nom. Size (Diam)	Weight (+/-10%)		LDBF (acc. MEG4)	MBL (acc. ISO 2307)
Inches	mm	kgs/100 mtr	kgs/220 mtr	tn	tn
2”	16	19,2	42,2	21,5	23,6
2 ¼”	18	22,6	49,7	27,6	30,5
2 ½”	20	28,4	62,5	33,6	36,9
2 ¾”	22	32,6	71,7	41,1	45,2
3”	24	42,4	93,3	48,5	53,4
3 ¼”	26	47,1	103,6	56,9	62,6
3 ½”	28	57,4	126,3	66,3	72,9
3 ¾”	30	72,8	160,2	75,6	83,2
4”	32	76	167,2	81,2	89,3
4 ¼”	34	78,6	172,9	85,9	94,5
4 ½”	36	85,3	187,7	98	107,8
4 ¾”	38	93,3	205,3	109,2	120,2
5”	40	107,9	237,4	122,3	134,6
5 ¼”	42	115,8	254,8	134,5	147,9
5 ½”	44	124,7	274,3	150,3	165,3
5 ¾”	46	152,9	336,4	170,4	187,5
6”	48	162,6	357,7	187,9	206,7
6 ¼”	50	170,2	374,4	201,4	221,6
6 ½”	52	183,8	404,4	219,7	241,8
7”	56	206,7	454,7	257,7	283,5
7 ½”	60	229,9	505,8	275	302,5
8”	64	252,6	555,7	315,6	347,1
8 ½”	68	290,5	639,1	369,6	406,5
9”	72	318,9	701,6	392	431,2
9 ½”	76	347,4	764,3	437	480,7
10”	80	404,4	889,7	492,7	542
10 ½”	84	439,3	966,5	541,3	595,4
