High Performance Ropes | UHMWPE Ropes | NIKA-Siri® X-12

NIKA-Siri® X-12 Rope

NIKA-Siri® X-12 ropes are high Modulus / high performance UHMWPE 12-strand ropes, where each strand is a 12-strand UHMWPE rope over-braided with High Tenacity Polyester sheath, resulting in a robust rope structure.

The special engineered structure of NIKA-Siri® X-12 ropes gives them very high abrasion durability. This unique structure protects against both external and internal abrasion. Each strand is coated with NikaThane-J coating and undergoes a fine heat-setting process that enhances the rope-strand’s breaking strength.

APPLICATIONS: MOORING / TOW LINES / STS OPERATIONS (to be used with synthetic tails) / ANCHORING / OFFSHORE

NIKA-Siri® X-12 ropes are 7 times stronger than steel ropes and 3 times stronger than polyester on a weight by weight comparison. When compared to wire ropes, NIKA-Siri® X-12 ropes are stronger on a weight by weight basis, lighter and easier to handle, safer to use with reduced recoiling upon breaking. If floating properties are required then instead of Polyester, the sheath can be made using UHMWPE fibers that enhance also the abrasion resistance even more.

NIKA-Siri® X-12 ropes have been field tested in tugboat operations, a highly demanding application, with exceptional results.

NIKA-Siri® X-12 ropes are an excellent wire-rope alternative and some of the reasons are the following:

  1. Most cost effective ropes to purchase due to lower labor requirements in operations and decreased mooring & towing operating times
  2. Safer and easier to use due to their high strength and low weight.
  3. 2-3 times longer service life
  4. Negligible maintenance costs

NIKA-Siri® X-12 comply with OCIMF’s latest regulations & recommendations for the safe mooring of the tanker vessels.

Siri High Performance Ropes
NikaFiber
NikaLube
NikaThane
LR Type Approval

Technical Specifications

Specific Gravity: 1.00 (Floating)
Elongation at breaking: 4% (when new)
Melting point: 145oC (UHMWPE) - 265oC (PES)
Resistance to UV radiation: Excellent
Chemical Resistance to ALKALI: Excellent
Chemical Resistance to ORGANIC SOLVENT: Very Good
Chemical Resistance to ACID: Good. Resistant to H2SO4 in temperatures up to 25oC

Technical Datasheet
Size (Circ) Size (Diam) Weight (+/- 5%) Minimum Breaking Load
inches mm Kilos /100m Kilos /220m Tons
4 1/2 36 89 196 84
5 40 111.2 244 101
5 1/2 44 137 301 129
6 48 159 350 163
6 1/2 52 203.6 448 199
7 56 216.5 476.5 219
7 1/2 60 248 545.5 240
8 64 280 616 273
8 1/2 68 315 693 297
9 72 356 783 348
9 1/2 76 398 875.5 391
10 80 430 946 440
10 1/2 84 484 1065 487
11 88 541.4 1191 532
